Solis Single Phase Grid-Tied Inverter: S5-GC(25-50)K

At 25kW and above, a solar inverter stops being a simple grid-tied box and starts being a piece of commercial infrastructure, one that needs to handle multiple orientations, integrate with monitoring systems, and hold up under continuous industrial-grade operation. The S5-GC(25-50)K is Solis's answer for that tier, and rather than list generic specs, it's worth walking through it the way Solis itself categorizes the unit: efficient, smart, safe, and economic.

KEY FEATURES

Efficient

Max efficiency on this series reaches 98.8%, with EU efficiency up to 98.4% depending on the specific model. The 3 or 4 MPPT design (varying by variant) supports multiple orientation system designs, useful on commercial roofs where panel arrays don't all face the same direction. An optional night-time PID recovery function actively works to increase overall system yield rather than just preventing further degradation, and a wide voltage range with low startup voltage means the unit starts generating earlier in the day and keeps working longer into low-light conditions.

Smart

This series is built for remote visibility, not just generation. Intelligent string monitoring with smart I-V curve scanning means a fault on one string across a large array can be pinpointed without a technician walking the entire site. Communication runs over RS485, WiFi, or GPRS, and the unit registers directly onto SolisCloud, supporting remote firmware upgrades and control. For a commercial installation where the O&M team isn't necessarily on-site daily, that remote diagnostic capability is a genuinely practical feature, not a checkbox.

Safe

IP66 ingress protection handles dust and moisture, and AFCI 2.0 (optional) proactively reduces fire risk by detecting developing arc faults before they escalate. The datasheet also confirms compliance with IS 16169 / IS 16221 (BIS), the relevant Indian Bureau of Standards certification, alongside IEC 61683, IEC 61727, IEC 62116, and IEC 62109 safety and EMC standards. Solis notes the unit uses globally recognised branded componentry specifically for longer working life, a detail that matters more at this investment scale than it does on a small residential unit.

Economic

A DC/AC ratio above 150% lets a project oversize the DC array relative to the inverter's AC rating, extracting more usable energy from the same inverter capacity. Support for high-power modules keeps the total module count, and installation labor, lower for a given system size, and GPRS/WiFi communication reduces the wiring runs a wired monitoring setup would otherwise require. Cooling is handled by an intelligent fan system, rated to keep the unit within safe operating range even under sustained high-output conditions typical of a commercial rooftop or ground-mount site.

Choosing a Model in the Range

The S5-GC(25-50)K spans six individual models, not one fixed unit:

The HV variants exist specifically for sites running on a 480V grid connection rather than standard 400V, worth confirming with your EPC or electrical contractor before specifying a model, since the two aren't interchangeable on different grid infrastructure.

Solis On-Grid Availability and Pricing

Pricing on the S5-GC(25-50)K varies by model and project scope, so it isn't published here. Contact our team for a current quote, or view the full datasheet for the complete technical specification sheet.

Browse the rest of the Solis on-grid inverter range for other capacities, from residential through utility-scale. OSG Oriana India Pvt Ltd is the authorized PAN India distributor for Solis on-grid inverters, with genuine manufacturer warranty support across the full lineup.
