Solis On-Grid Inverters
Solis Three Phase Grid-Tied Inverter: S6-GC3P(150-200)K07-ND
On this page
This is the top of Solis's on-grid string inverter range in India, and it's built for a specific kind of project: large ground-mount or big-roof commercial sites running high-current bifacial modules, where a handful of 150-200kW units cover the same total capacity a much larger fleet of smaller inverters would otherwise need.
Engineered for High-Current Bifacial Arrays
The standout spec here is a single MPPT maximum current of 54A, specifically sized to match large-current bifacial modules rather than being an incidental capability. Across 7 MPPTs and up to 21 input strings, the unit supports a DC/AC ratio above 150%, letting a project oversize its array relative to the inverter's AC rating and extract more usable energy from the same installed capacity. Max efficiency reaches 98.8%, with EU efficiency at 98.3%, competitive figures even at this scale.
What to Know Before Siting This Unit
A few practical details matter more here than on smaller commercial units. Noise emission runs up to 80 dB(A), noticeably louder than Solis's smaller commercial and residential lines, worth factoring into placement decisions, especially on sites with any proximity to occupied spaces. At 105kg, it's also a genuinely heavy unit, mounting and structural planning should account for that early rather than as an installation-day surprise. On the monitoring side, it adds Bluetooth connectivity alongside the standard app, giving installers a direct local pairing option during commissioning without needing network access first.
150K vs 200K-HV Specifications
Spec | S6-GC3P150K07-NV | S6-GC3P200K07-HV |
|---|---|---|
Rated output power | 150 kW | 200 kW (@35°C) |
Max. output power | 165 kW | 220 kW |
Rated grid voltage | 3/N/PE, 220V/380V or 230V/400V | 3/PE, 480V |
Max. output current | 250.6 A | 240.6 A |
MPPT / max. strings | 7 / 21 | 7 / 21 |
Max. input current | 7 × 54 A | 7 × 54 A |
Weight | 105 kg | 105 kg |
Ingress protection | IP66 | IP66 |
Cooling | Intelligent fan-cooling | Intelligent fan-cooling |
The 200K-HV variant is built specifically for 480V grid infrastructure, not a straightforward capacity upgrade of the 150K on the same electrical setup, confirm your site's grid voltage before specifying between the two.
Solis On-Grid Pricing and Availability
Pricing for the S6-GC3P(150-200)K07-ND depends on the model and project scope, so it isn't published here. Contact our team for a current quote, or view the full datasheet for the complete technical specification sheet.
Browse the rest of the Solis on-grid inverter range for other capacities. OSG Oriana India Pvt Ltd is the authorized PAN India distributor for Solis on-grid inverters, with genuine manufacturer warranty support across the full lineup.
Related reading:
FAQs
1. What capacity does the S6-GC3P(150-200)K07-ND cover?
150kW and 200kW, across two models: S6-GC3P150K07-NV and S6-GC3P200K07-HV.
2. Why is the single MPPT current rated at 54A?
It's specifically sized to match large-current bifacial modules, letting the inverter fully utilize high-output bifacial arrays rather than derating them.
3. How loud is this inverter?
Up to 80 dB(A), noticeably louder than Solis's smaller commercial units, worth factoring into site placement.
4. What's the difference between the 150K and 200K-HV models?
The 200K-HV is built for 480V grid infrastructure, while the 150K runs on standard 220V/380V or 230V/400V grids, they're not interchangeable on the same electrical setup.
5. Where can I get pricing for this inverter?
Pricing isn't published online since it varies by model and project. Contact our team for a current quote.
